ERG-7004-FD3-4
7-inch IPS Wireless Reversing Camera Kit with Four Cameras
Open full-size image ↗
1 / 11
- Screen size
- 7-inch
- Display resolution
- 1024 × 600 IPS
- Camera resolution
- AHD 720P
- Included cameras
- 4
Four-camera wireless reversing kit with a 7-inch 1024 × 600 IPS monitor, quad-view display and simultaneous four-channel recording. Includes four AHD 720P cameras with IP68 protection.
Specifications
General
- Screen size
- 7-inch
- Display resolution
- 1024 × 600 IPS
- Camera resolution
- AHD 720P
- Included cameras
- 4
- Wireless frequency
- 2400–2483.5 MHz
- Recording
- 4 channels simultaneously
Show 1 more specifications
- Storage
- Up to 128GB SD card; not included
Monitor
- Power supply
- DC 9–36V
- Video system
- PAL / NTSC
- Brightness
- 500 cd/m²
- Contrast ratio
- 500:1
- Operating temperature
- -20°C to +70°C
Cameras
- Image sensor
- 1/3-inch AHD CMOS
- Viewing angle
- 120°
- Waterproof rating
- IP68
- Night vision
- Infrared
- Power supply
- DC 12–24V
Full product details
Product overview
ERG-7004-FD3-4
Four-camera wireless reversing kit with a 7-inch 1024 × 600 IPS monitor, quad-view display and simultaneous four-channel recording. Includes four AHD 720P cameras with IP68 protection.
Product details
- 7-inch IPS monitor with quad-view display and removable sun visor.
- Four AHD 720P cameras with 120° viewing angles and infrared night vision.
- 2.4GHz digital wireless transmission.
- Simultaneous four-channel recording; supports up to 128GB SD storage. SD card not included.
Package contents
One 7-inch IPS monitor, four cameras, U-bracket, monitor sun visor, antennas, power cords, installation tools and manual.
Confirm vehicle fitment, installation conditions and system configuration when requesting a quote.
